Insay haydrolik sistem dizayn, lik nɔ de ɛva bi opshɔn. Di we aw dɛn kin pik fɔ fit di fitin rili impɔtant fɔ mek shɔ se dɛn ebul fɔ du dɛn wok fayn fayn wan, dɛn sef, ɛn dɛn kin abop pan dɛn. Tu pan di mɔs prominɛnt sɔlvishɔn fɔ ay-prɛshɔn aplikeshɔn dɛn na
ED (bayt-tayp) fitin ɛn
O-ring fes sil (ORF) fitin dɛn.
Bɔt uswan rayt fɔ yu aplikeshɔn? Dis gayd de go insay di men difrɛns, advantej, ɛn fayn yus kes fɔ ɛni wan fɔ ɛp yu fɔ disayd fɔ du sɔntin we yu no.
Di kɔr difrɛns: aw dɛn sial
di fawndeshɔnal difrɛns de na dɛn silin mɛkanism.
1. O-ring fes sil (ORFS) Fitins: Elastik silin
Wan ORFS fitin de yuz wan resilient O-ring fɔ mek wan bɔbul-tayt sil. Di fitin gɛt flat fes wit grov we de ol di O-ring. we di nat tayt, di flat fes fכ di mating kכmכpכnt de kכmprεs di O-ring insay in grov.
Ki Advantej: Di sil na di
elastik difɔmeshɔn fɔ di O-ring , we de kɔmpɛns fɔ di sɔfayz impɛrɛfɛkshɔn ɛn vaybreshɔn dɛn we de na di sɔfa. Di mɛtal-to-mɛtal kɔntakt fɔ di flɛnch dɛn de gi mɛkanikal trɛnk, we di O-ring de handel di silin.
2. ED (bit-tayp) fitin dɛn: Mɛtal-to-mɛtal silin
Wan ED fitin de dipen pan wan prɛsishɔn mɛtal-to-mɛtal kɔntakt. I gɛt tri pat dɛn: di bɔdi we fit (we gɛt 24° kɔn), we gɛt shap ed fɛrul, ɛn nat. As di nat tayt, i de drɛb di fɛrul pan di tiub.
Ki Advantej: Di frɔnt sfɛrikal sɔfays fɔ di fɛrul de bit insay di fitin in 24° kɔn, we de mek wan
rigid mɛtal-to-mɛtal sil . Wan tɛm, di fɛrul in kɔt ed dɛn kin bit insay di tiub wɔl fɔ mek i grip ɛn mek dɛn nɔ pul am.
Chat fɔ kɔmpia di ed to di ed to di ed to di ed to di ed.
Fit
O-ring fes sil (ORF) fitin
ed (bit-tayp) fitin
Prinsipul fɔ Silin .
Elastik O-ring kɔmpreshɔn .
Metal-to-mɛtal bayt .
Vaybreshɔn rɛsistɛns .
Wɛl dɔn. Di O-ring de akt lɛk shɔk absɔba.
Gud.
Prɛshɔn Spik Resistɛns .
Big pas. Elastik sil de absɔb pulseshɔn dɛn.
Gud.
I izi fɔ instɔl .
Simpul. tork-based; less skill-intensive.
Tranga. I nid fɔ tek tɛknik ɔ wan tin we dɛn kin yuz fɔ du wetin dɛn want fɔ du bifo dɛn du am.
Riyuzabiliti / Mentɛnans .
Wɛl dɔn. Simply riples di low-cost O-ring.
Pɔ. Di ferrule in bayt na pɔrmanent; Nɔto fayn tin fɔ yuz bak.
Misalaynmɛnt tolɛreshɔn .
Ay. Di O-ring kin kɔmpɛns fɔ smɔl ɔfset dɛn.
Lo. Rikways gud alaynɛshɔn fɔ wan prɔpa sil.
Tempracha resistans .
Limited bay di O-ring matirial (ɛgz., FKM fɔ ay temp).
Big pas. No elastomer fɔ degrade.
Kεmikכl kכmpatibiliti .
dipεndεnt pan O-ring mεtirial sεlεkshכn.
Wɛl dɔn. Inert mɛtal sil de handle agresiv fluid dɛn.
Aw fɔ pik: Di tin dɛn we dɛn kin yuz fɔ mek di aplikeshɔn dɛn we dɛn kin yuz fɔ du di wok
Choose O-Ring Face Seal (ORFS) fitin if:
Yu ikwipmɛnt de wok na say dɛn we gɛt bɔku vaybreshɔn (ɛgz., mobayl haydrolik, kɔnstrɔkshɔn, agrikalchɔral, ɛn mayning mashin).
Yu nid fɔ diskɔnekt ɛn rikonɛkt layn dɛn ɔltɛm fɔ mek dɛn chenj ɔ fɔ chenj di kɔnfigyushɔn.
I izi ɛn spid fɔ asɛmbli na prɔyorities , ɛn di instɔla skil lɛvɛl kin difrɛn.
Yu sistɛm de ɛkspiriɛns signifyant prɛshɔn sɔj.
Lik-fri rilaybiliti na di nɔ-nɛgɔshiabl tɔp prayoritɛd fɔ mɔs standad industrial aplikeshɔn dɛn.
ORFs de we bɔku pipul dɛn kin tek as di mɔdan, ay-rilaybiliti standad fɔ nyu dizayn dɛn usay fluid ɛn tɛmpracha kɔmpitabl wit di O-ring dɛn we de.
Pik ED (bit-tayp) fitin dɛn if:
Yu sistem de yuz fluid we nɔ kɔmpitabl wit kɔmɔn ɛlastɔm , lɛk fɔsfɛt ɛsta-bɛs (skydrol) haydrolik fluid.
Yu de wok na ekstrim tempɔret ɛnvayrɔmɛnt we pas di limit dɛn fɔ ay-tɛmpracha O-ring dɛn.
Yu de wok insay wan sistɛm ɔ industri standad we dɔn de (ɛgz., sɔm ɛrospɛs ɔ lɛgsi industrial sistɛm dɛn) we de spɛsifa dɛn yus.
Space constraints ar extreme , ɛn di mɔ kɔmpakt dizayn fɔ wan ED fitin nid fɔ de.
Di verdikt: Wan klia tren to ORF
fɔ di bɔku bɔku aplikeshɔn dɛn—espɛshali insay mobayl ɛn industrial ikwipmɛnt—
O-ring fes sil fitin dɛn na di rɛkɔmɛnd chuk. Dɛn vaybreshɔn rɛsistɛns we nɔ gɛt wan kɔmpitishɔn, izi fɔ instɔl, ɛn ful-pruf silin pefɔmɛns de mek dɛn bi di supia sɔlvishɔn fɔ mek dɛn nɔ lik ɛn ridyus di mentenɛns kɔst.
ED fitin dɛn stil de bi spɛshal sɔlvishɔn fɔ nich aplikeshɔn dɛn we involv ekstrim tɛmpracha, agresiv fluid, ɔ spɛshal lɛgsi sistɛm dɛn.
